KTM 1190 RC8 R User Manual

6 CONTROLS 98
400460-01
– Press the button and the button for 3 - 5 seconds.
– Press the button twice until the symbol shows SETTINGS in the info display.
– Press the MODE button briefly.
– Press the MODE button briefly.
RPM1 and RPM2 appear on the info display.
The engine speed after RPM1 flashes.
Info
The engine speed can be set at intervals of 50.
RPM1 is the engine speed above which the shift warning light starts to flash.
– Set the engine speed with the button or the button .
– Press the MODE button briefly.
The engine speed after RPM2 flashes.
Info
RPM2 is the engine speed above which the shift warning light lights up con-
stantly. If RPM1 = RPM2, the shift warning light lights up constantly when you
reach the engine speed set.
– Set the engine speed with the button or the button .
– Press the MODE button briefly.
The settings are stored and the display switches to the SETTINGS menu.
Info
At delivery, RPM1 is set to 10000 and RPM2 to 10500.
– Press the button briefly and repeatedly until the symbol shows BACK... in the info
display.

KTM 1190 RC8 R Specifications

General

Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Compression Ratio	13.5:1
Transmission	6-speed
Rear Suspension	WP Monoshock
Fuel Tank Capacity	16.5 liters
Dry Weight	184 kg
Fuel System	Electronic fuel injection
Engine Type	V-twin, 4-stroke
Power	129 kW (175 hp) @ 10, 250 rpm
Torque	123 Nm @ 8, 000 rpm
Frame	Chromium-Molybdenum trellis frame, powder coated
Front Brake	2 x Brembo four-piston calipers, 320 mm discs
Rear Brake	220 mm disc, 2-piston caliper
Seat Height	805 mm
