KTM 1190 RC8 R User Manual

14 ELECTRICAL SYSTEM 219
100748-10
Main work
–
Turn the screw

to adjust the headlight range.
Guideline
A motorcycle with rider, including the luggage and a passenger (where applicable)
the light cut off must be aligned exactly on the lower mark (when checking headlight
adjustment).
Info
Turn clockwise to increase the headlight range; turn counterclockwise to reduce
the headlight range.
If you have a payload, you may have to correct the headlight range.
14.10 Activating/deactivating ignition key
Info
The orange programming key must only be used for activating and deactivating!
401114-10
Loss of a black ignition key (second black ignition key available):
If a black ignition key is lost or replaced, the black ignition keys must be individually
activated/deactivated using the orange programming key. This will also prevent the vehi-
cle from being operated without authorization with the lost black ignition key.
The following procedure deactivates all activated black ignition keys that are not
included in the procedure.
– Press the emergency OFF switch into the position .

KTM 1190 RC8 R Specifications

General

Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Compression Ratio	13.5:1
Transmission	6-speed
Rear Suspension	WP Monoshock
Fuel Tank Capacity	16.5 liters
Dry Weight	184 kg
Fuel System	Electronic fuel injection
Engine Type	V-twin, 4-stroke
Power	129 kW (175 hp) @ 10, 250 rpm
Torque	123 Nm @ 8, 000 rpm
Frame	Chromium-Molybdenum trellis frame, powder coated
Front Brake	2 x Brembo four-piston calipers, 320 mm discs
Rear Brake	220 mm disc, 2-piston caliper
Seat Height	805 mm
