14 ELECTRICAL SYSTEM 212
Close the fuse box cover.
Finishing work
Fit the seat. ( p. 170)
14.6 Changing the low beam bulb
Note
Damage to reflectorReduced brightness.
Grease on the lamp will evaporate due to the heat and be deposited on the reflector. Clean the lamp and keep it free of grease before
mounting.
Preparatory work
Switch off all power consumers and the engine.
100742-10
Main work
Fold up the combination instrument. Pull the lug
out of the rubber retainer
.
Remove the rubber retainer.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the KTM 1190 RC8 R and is the answer not in the manual?

KTM 1190 RC8 R Specifications

General IconGeneral
Displacement1195 cc
Bore x Stroke105 mm x 69 mm
Compression Ratio13.5:1
Transmission6-speed
Rear SuspensionWP Monoshock
Fuel Tank Capacity16.5 liters
Dry Weight184 kg
Fuel SystemElectronic fuel injection
Engine TypeV-twin, 4-stroke
Power129 kW (175 hp) @ 10, 250 rpm
Torque123 Nm @ 8, 000 rpm
FrameChromium-Molybdenum trellis frame, powder coated
Front Brake2 x Brembo four-piston calipers, 320 mm discs
Rear Brake220 mm disc, 2-piston caliper
Seat Height805 mm
