KTM 1190 RC8 R User Manual

6 CONTROLS 51
The calculation of this value starts with the first speed signal and ends 3 seconds after the
last speed signal.
Avs 2 shows the average speed and is coupled with Trip 2 and Time 2.
Press the button . No function
Press the button . No function
Press the button
and the button for
3 - 5 seconds.
The display changes to the SET‑UP menu
Press the MODE but-
ton for 3 - 5 sec-
onds.
The display of Trip 2, Time 2 and Avs 2 is reset
Press the MODE but-
ton briefly.
Next display mode
6.13.13 Gear display menu, ODO/Trip 1/Gear
401131-01
Condition
Alternative 1
• The ignition is on.
• The motorcycle is stationary.
• ROAD mode
Alternative 2
• The ignition is on.
• The motorcycle is being ridden.
• ROAD mode
– Press the MODE button briefly and repeatedly until ODO, Trip 1, and Gear appear in the
info display.
ODO shows the total distance covered.

KTM 1190 RC8 R Specifications

General

Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Compression Ratio	13.5:1
Transmission	6-speed
Rear Suspension	WP Monoshock
Fuel Tank Capacity	16.5 liters
Dry Weight	184 kg
Fuel System	Electronic fuel injection
Engine Type	V-twin, 4-stroke
Power	129 kW (175 hp) @ 10, 250 rpm
Torque	123 Nm @ 8, 000 rpm
Frame	Chromium-Molybdenum trellis frame, powder coated
Front Brake	2 x Brembo four-piston calipers, 320 mm discs
Rear Brake	220 mm disc, 2-piston caliper
Seat Height	805 mm
