KTM 1190 RC8 R User Manual

11 SERVICE WORK ON THE CHASSIS 170
11.7 Fitting the seat
B01323-10
– Position the recesses of the seat to the lugs on the frame, lower the rear end and simul-
taneously push it forward.
– Lock the seat by turning the ignition key in the seat lock.
– Remove the ignition key from the seat lock.
– Finally, check that the seat is correctly mounted.
11.8 Mounting the helmet lock on the vehicle
Warning
Danger of accidents Impairment of vehicle handling and vehicle operation if a helmet or helmet lock is attached to the vehicle.
– Do not use the helmet lock for holding a helmet or other objects during the journey. Always remove the helmet lock before start-
ing out.
B01324-10
– Remove the seat. ( p. 169)
–
Position the steel cable from the tool kit with one loop on the lug

.
Steel cable (60012015000)
– Guide the steel cable through the helmet opening.
– Then position the free loop of the steel cable on the lug.
– Position the helmet carefully on the side of the vehicle.
– Fit the seat. ( p. 170)

KTM 1190 RC8 R Specifications

General

Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Compression Ratio	13.5:1
Transmission	6-speed
Rear Suspension	WP Monoshock
Fuel Tank Capacity	16.5 liters
Dry Weight	184 kg
Fuel System	Electronic fuel injection
Engine Type	V-twin, 4-stroke
Power	129 kW (175 hp) @ 10, 250 rpm
Torque	123 Nm @ 8, 000 rpm
Frame	Chromium-Molybdenum trellis frame, powder coated
Front Brake	2 x Brembo four-piston calipers, 320 mm discs
Rear Brake	220 mm disc, 2-piston caliper
Seat Height	805 mm
