KTM 1190 RC8 R User Manual

23 TECHNICAL DATA 255
1st gear 14:36
2nd gear 16:30
3rd gear 20:30
4th gear 21:27
5th gear 23:26
6th gear 25:26
Mixture preparation Electronically controlled fuel injection
Ignition system Contactless controlled fully electronic ignition with digital ignition
adjustment
Alternator 12 V, 450 W
Spark plug
Inside spark plug NGK LKAR9BI9
Outside spark plug NGK LMAR7A-9
Electrode gap, spark plug 0.8… 0.9 mm (0.031… 0.035 in)
Cooling Water cooling, permanent circulation of coolant by water pump
Idle speed 1,500… 1,600 rpm
Cold start device Electric starter
23.2 Motor tightening torques
Screw, damping plate, clutch cover EJOT ALtracs
®
M6x10 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, retaining bracket, valve cover,
rear
EJOT ALtracs
®
M6x10 10 Nm (7.4 lbf ft) –
Hose clip, intake flange M4 1.5 Nm (1.11 lbf ft) –
Remaining engine screws M5 6 Nm (4.4 lbf ft) –
Screw, bearing retainer M5 6 Nm (4.4 lbf ft) Loctite
®
243™

KTM 1190 RC8 R Specifications

General

Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Compression Ratio	13.5:1
Transmission	6-speed
Rear Suspension	WP Monoshock
Fuel Tank Capacity	16.5 liters
Dry Weight	184 kg
Fuel System	Electronic fuel injection
Engine Type	V-twin, 4-stroke
Power	129 kW (175 hp) @ 10, 250 rpm
Torque	123 Nm @ 8, 000 rpm
Frame	Chromium-Molybdenum trellis frame, powder coated
Front Brake	2 x Brembo four-piston calipers, 320 mm discs
Rear Brake	220 mm disc, 2-piston caliper
Seat Height	805 mm
