KTM 1190 RC8 R User Manual

6 CONTROLS 107
400466-01
– Press the button and the button for 3 - 5 seconds.
– Press the button four times until the symbol shows OPTIONS in the info display.
– Press the MODE button briefly.
– Press the button once until the symbol shows OPTION OUTTEMP in the info display.
– Press the MODE button briefly.
You see ENABLED or DISABLED in the info display.
– You can switch the external temperature display on/off with the button or the but-
ton.
– Press the MODE button briefly.
The settings are stored and the display changes to the OPTIONS menu.
– Press the button briefly and repeatedly until the symbol shows BACK... in the info
display.
– Press the MODE button briefly.
– Press the button briefly and repeatedly until the symbol shows EXIT SETUP in the
info display.
– Press the MODE button briefly.
6.14 Opening the filler cap
Danger
Fire hazard Fuel is highly flammable.
– Never refuel the vehicle near open flames or burning cigarettes, and always switch off the engine first. Be careful that no fuel is
spilt, especially on hot vehicle components. Clean up spilt fuel immediately.
– The fuel in the fuel tank expands when warm and may emerge if overfilled. Follow the instructions on refueling.

KTM 1190 RC8 R Specifications

General

Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Compression Ratio	13.5:1
Transmission	6-speed
Rear Suspension	WP Monoshock
Fuel Tank Capacity	16.5 liters
Dry Weight	184 kg
Fuel System	Electronic fuel injection
Engine Type	V-twin, 4-stroke
Power	129 kW (175 hp) @ 10, 250 rpm
Torque	123 Nm @ 8, 000 rpm
Frame	Chromium-Molybdenum trellis frame, powder coated
Front Brake	2 x Brembo four-piston calipers, 320 mm discs
Rear Brake	220 mm disc, 2-piston caliper
Seat Height	805 mm
