23 TECHNICAL DATA 264
Medium (standard) 85 N/mm (485 lb/in)
Hard 95 N/mm (542 lb/in)
Spring length 160 mm (6.3 in)
Gas pressure 10 bar (145 psi)
Static sag 11… 15 mm (0.43… 0.59 in)
Riding sag 28… 35 mm (1.1… 1.38 in)
Inbuilt length 290 mm (11.42 in)
Shock absorber fluid ( p. 270) SAE 2.5
23.9 Chassis tightening torques
Screw, side stand switch M4 2 Nm (1.5 lbf ft) Loctite
®
243™
Remaining frame bolts M5 5 Nm (3.7 lbf ft) –
Screw, brake fluid reservoir of rear brake M5 5 Nm (3.7 lbf ft) Loctite
®
243™
Screw, brake line holder M5 5 Nm (3.7 lbf ft) –
Screw, chain guard M5 5 Nm (3.7 lbf ft) –
Screw, chain sliding guard M5 5 Nm (3.7 lbf ft) –
Screw, fuel level indicator M5 3 Nm (2.2 lbf ft) –
Screw, fuel tank guard M5x12 3 Nm (2.2 lbf ft) –
Screw, painted trim parts M5 3.5 Nm (2.58 lbf ft) –
Screw, steering damper fixing bracket M5 5 Nm (3.7 lbf ft) Loctite
®
243™
Bolt, foot brake lever stub M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Remaining chassis nuts M6 10 Nm (7.4 lbf ft) –
Remaining chassis screws M6 10 Nm (7.4 lbf ft) –
Screw for wheel speed sensor bracket M6 3 Nm (2.2 lbf ft) Loctite
®
243™

KTM 1190 RC8 R Specifications

General

Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Compression Ratio	13.5:1
Transmission	6-speed
Rear Suspension	WP Monoshock
Fuel Tank Capacity	16.5 liters
Dry Weight	184 kg
Fuel System	Electronic fuel injection
Engine Type	V-twin, 4-stroke
Power	129 kW (175 hp) @ 10, 250 rpm
Torque	123 Nm @ 8, 000 rpm
Frame	Chromium-Molybdenum trellis frame, powder coated
Front Brake	2 x Brembo four-piston calipers, 320 mm discs
Rear Brake	220 mm disc, 2-piston caliper
Seat Height	805 mm
