23 TECHNICAL DATA 265
Screw, exhaust clamp M6 8 Nm (5.9 lbf ft) –
Screw, exhaust heat shield M6 15 Nm (11.1 lbf ft) –
Screw, foot brake cylinder M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, foot brake lever M6 15 Nm (11.1 lbf ft) Loctite
®
243™
Screw, fuel pump M6 6 Nm (4.4 lbf ft) –
Screw, mirror bracket M6 6 Nm (4.4 lbf ft) –
Screw, shift lever stub M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, shift rod M6 12 Nm (8.9 lbf ft) Loctite
®
243™
Screw, shift shaft deflector on chain
securing guide
M6 7 Nm (5.2 lbf ft) Loctite
®
243™
Screw, shift shaft deflector on shift
shaft
M6 18 Nm (13.3 lbf ft) Loctite
®
243™
Fork end pinch bolts M8 15 Nm (11.1 lbf ft) –
Nut, forked bracket on foot brake lever M8 30 Nm (22.1 lbf ft) Loctite
®
243™
Remaining chassis nuts M8 25 Nm (18.4 lbf ft) –
Remaining chassis screws M8 25 Nm (18.4 lbf ft) –
Screw for lifting gear support, rear M8 18 Nm (13.3 lbf ft) –
Screw of rear brake caliper M8 22 Nm (16.2 lbf ft) Loctite
®
243™
Screw, bottom triple clamp M8 15 Nm (11.1 lbf ft) –
Screw, clamp, eccentric shaft of deflec-
tor
M8 18 Nm (13.3 lbf ft) –
Screw, front brake disc M8 30 Nm (22.1 lbf ft) Loctite
®
243™
Screw, front footrest bracket M8 25 Nm (18.4 lbf ft) Loctite
®
243™
Screw, handlebar stub M8 20 Nm (14.8 lbf ft) –
Screw, ignition lock M8 16 Nm (11.8 lbf ft) Loctite
®
243™

KTM 1190 RC8 R Specifications

General

Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Compression Ratio	13.5:1
Transmission	6-speed
Rear Suspension	WP Monoshock
Fuel Tank Capacity	16.5 liters
Dry Weight	184 kg
Fuel System	Electronic fuel injection
Engine Type	V-twin, 4-stroke
Power	129 kW (175 hp) @ 10, 250 rpm
Torque	123 Nm @ 8, 000 rpm
Frame	Chromium-Molybdenum trellis frame, powder coated
Front Brake	2 x Brembo four-piston calipers, 320 mm discs
Rear Brake	220 mm disc, 2-piston caliper
Seat Height	805 mm
