23 TECHNICAL DATA 266
Screw, rear brake disc M8 30 Nm (22.1 lbf ft) Loctite
®
243™
Screw, rear footrest bracket M8 25 Nm (18.4 lbf ft) –
Screw, rear footrest bracket (footrest
bracket not mounted)
M8x25 15 Nm (11.1 lbf ft) –
Screw, shift lever M8 25 Nm (18.4 lbf ft) Loctite
®
243™
Screw, side stand bracket M8 25 Nm (18.4 lbf ft) Loctite
®
243™
Screw, spring holder on side stand
bracket
M8 15 Nm (11.1 lbf ft) Loctite
®
243™
Screw, steering damper clamp on con-
sole
M8 20 Nm (14.8 lbf ft) Loctite
®
243™
Screw, steering damper fixing bracket
on triple clamp
M8 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, steering stem M8 20 Nm (14.8 lbf ft) –
Screw, subframe M8 20 Nm (14.8 lbf ft) Loctite
®
243™
Screw, top triple clamp M8 17 Nm (12.5 lbf ft) –
Remaining chassis nuts M10 45 Nm (33.2 lbf ft) –
Remaining chassis screws M10 45 Nm (33.2 lbf ft) –
Screw, connecting lever, shock absorber
deflector
M10 45 Nm (33.2 lbf ft) Loctite
®
243™
Screw, engine bearer M10 45 Nm (33.2 lbf ft) –
Screw, shock absorber M10 45 Nm (33.2 lbf ft) Loctite
®
243™
Screw, side stand M10 35 Nm (25.8 lbf ft) Loctite
®
243™
Rear sprocket bolt M10x1.25 50 Nm (36.9 lbf ft) Loctite
®
243™
Screw, front brake caliper M10x1.25 45 Nm (33.2 lbf ft) Loctite
®
243™
Nut of bell crank on frame M14x1.5 100 Nm (73.8 lbf ft) –
Lambda sensor M18x1.5 45 Nm (33.2 lbf ft) –
