KTM 1190 RC8 R User Manual

11 SERVICE WORK ON THE CHASSIS 168
11.3 Raising the front of the motorcycle with lifting gear
Note
Danger of damage The parked vehicle may roll away or fall over.
– Always place the vehicle on a firm and even surface.
Preparatory work
– Raise the rear of the motorcycle with lifting gear. ( p. 167)
B01322-01
Main work
– Move the handlebar to the straight-ahead position. Align the lifting gear at the front
with the adapters to the fork legs.
Front wheel stand (61029055300)
Info
Always raise the rear of the motorcycle first.
– Raise the motorcycle at the front.
11.4 Taking the motorcycle off of the front wheel stand
Note
Danger of damage The parked vehicle may roll away or fall over.
– Always place the vehicle on a firm and even surface.
– Secure the motorcycle against falling over.
– Remove the lifting gear from the front.

KTM 1190 RC8 R Specifications

General

Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Compression Ratio	13.5:1
Transmission	6-speed
Rear Suspension	WP Monoshock
Fuel Tank Capacity	16.5 liters
Dry Weight	184 kg
Fuel System	Electronic fuel injection
Engine Type	V-twin, 4-stroke
Power	129 kW (175 hp) @ 10, 250 rpm
Torque	123 Nm @ 8, 000 rpm
Frame	Chromium-Molybdenum trellis frame, powder coated
Front Brake	2 x Brembo four-piston calipers, 320 mm discs
Rear Brake	220 mm disc, 2-piston caliper
Seat Height	805 mm
