6 CONTROLS 60
6.13.20 Gear display menu, LastLap/RaceTrip/Gear
401145-01
Condition
Alternative 1
The ignition is on.
The motorcycle is stationary.
RACE mode
Alternative 2
The ignition is on.
The motorcycle is being ridden.
RACE mode
Press the MODE button briefly and repeatedly until LastLap, RaceTrip, and Gear appear in
the info display.
LastLap shows the lap time of the last lap.
RaceTrip shows the distance covered since the last reset. For example, between two refuel-
ing stops. RaceTrip is always running and counts up to 999.9.
Gear shows the gear currently engaged.
Press the button . No function
Press the button . No function
Press the button
and the button for
3 - 5 seconds.
The display changes to the SETUP menu
Press the MODE but-
ton for 3 - 5 sec-
onds.
All values in RACE mode are reset (except RACEODO)
Press the MODE but-
ton briefly.
Next display mode

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the KTM 1190 RC8 R and is the answer not in the manual?

KTM 1190 RC8 R Specifications

General IconGeneral
Displacement1195 cc
Bore x Stroke105 mm x 69 mm
Compression Ratio13.5:1
Transmission6-speed
Rear SuspensionWP Monoshock
Fuel Tank Capacity16.5 liters
Dry Weight184 kg
Fuel SystemElectronic fuel injection
Engine TypeV-twin, 4-stroke
Power129 kW (175 hp) @ 10, 250 rpm
Torque123 Nm @ 8, 000 rpm
FrameChromium-Molybdenum trellis frame, powder coated
Front Brake2 x Brembo four-piston calipers, 320 mm discs
Rear Brake220 mm disc, 2-piston caliper
Seat Height805 mm
