13 WHEELS, TIRES 194
13.3 Removing the rear wheel
Preparatory work
– Raise the rear of the motorcycle with lifting gear. ( p. 167)
C00339-10
Main work
–
Remove nut
.
–
Remove chain adjuster
.
–
Remove wheel spindle
.
C00340-01
– Push the rear wheel as far forward as possible and then remove the chain from the rear
sprocket.
Info
Cover the components to protect them against damage.
Warning
Danger of accidents Reduced braking efficiency due to damaged brake discs.
– Always lay down the wheel in such a way that the brake discs are not dam-
aged.
– Pull the rear wheel back and take it out of the swingarm.
Info
Do not operate the foot brake lever when the rear wheel is removed.
