KTM 1190 RC8 R User Manual

17 SERVICE WORK ON THE ENGINE 234
17.5 Installing the oil filter
100776-10
–
Insert oil filter

.
–
Lubricate the O-ring of the oil filter cover. Position oil filter cover

.
– Mount and tighten the screws.
Guideline
Remaining engine screws M5 6 Nm (4.4 lbf ft)
17.6 Filling up with engine oil
Info
Too little engine oil or poor-quality engine oil results in premature wear to the engine.
B01336-10
Main work
– The oil must be topped up in two steps.
Engine oil 3.60 l (3.8 qt.) External
temperature:
≥ 0 °C (≥ 32 °F)
Engine oil
(SAE 10W/50)
( p. 268)
External
temperature:
< 0 °C (< 32 °F)
Engine oil (SAE
5W/40) ( p. 269)
–
Remove the dipstick

and top up the engine oil.

KTM 1190 RC8 R Specifications

General

Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Compression Ratio	13.5:1
Transmission	6-speed
Rear Suspension	WP Monoshock
Fuel Tank Capacity	16.5 liters
Dry Weight	184 kg
Fuel System	Electronic fuel injection
Engine Type	V-twin, 4-stroke
Power	129 kW (175 hp) @ 10, 250 rpm
Torque	123 Nm @ 8, 000 rpm
Frame	Chromium-Molybdenum trellis frame, powder coated
Front Brake	2 x Brembo four-piston calipers, 320 mm discs
Rear Brake	220 mm disc, 2-piston caliper
Seat Height	805 mm
