KTM 1190 RC8 R User Manual

11 SERVICE WORK ON THE CHASSIS 171
11.9 Removing the passenger seat
B01325-10
– Remove the seat. ( p. 169)
–
Activate the release lever

.
–
Take off the passenger seat

toward the top.
11.10 Mounting the passenger seat
B01326-01
Warning
Danger of accidents The passenger seat can come loose from the anchoring if it
is not mounted correctly.
– After mounting the passenger seat, check that it is locked correctly by
pulling up.
– Position the passenger seat in the space provided.
– Press down the passenger seat until it clicks into place.
– Finally, check that the passenger seat is correctly mounted.

KTM 1190 RC8 R Specifications

General

Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Compression Ratio	13.5:1
Transmission	6-speed
Rear Suspension	WP Monoshock
Fuel Tank Capacity	16.5 liters
Dry Weight	184 kg
Fuel System	Electronic fuel injection
Engine Type	V-twin, 4-stroke
Power	129 kW (175 hp) @ 10, 250 rpm
Torque	123 Nm @ 8, 000 rpm
Frame	Chromium-Molybdenum trellis frame, powder coated
Front Brake	2 x Brembo four-piston calipers, 320 mm discs
Rear Brake	220 mm disc, 2-piston caliper
Seat Height	805 mm
