6 CONTROLS 77
6.13.35 UNITS menu
401153-01
Condition
Alternative 1
• The ignition is on.
• The motorcycle is stationary.
• ROAD mode
Alternative 2
• The ignition is on.
• The motorcycle is stationary.
• RACE mode
– Press the button and the button for 3 - 5 seconds.
– Press the button three times until the symbol shows UNITS in the info display.
– Press the MODE button briefly.
In the SET KM/MILES menu, you can set the units for measuring speed and distance.
In the SET °C/°F menu, you can set the unit for the temperature display.
In the SET FUEL CONS menu, you can set the unit (liters) of the fuel consumption.
In the SET GAL US/UK menu, you can set the unit (gallons) of the fuel consumption.
In the BACK… menu, you can switch back to the SET‑UP menu.
The symbol indicates which menu can be activated with the MODE button.
Press the button . The arrow moves up
Press the button . The arrow moves down
Press the button
and the button for
3 - 5 seconds.
No function
Press the MODE but-
ton for 3 - 5 sec-
onds.
The menu in front of the arrow is selected

KTM 1190 RC8 R Specifications

General

Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Compression Ratio	13.5:1
Transmission	6-speed
Rear Suspension	WP Monoshock
Fuel Tank Capacity	16.5 liters
Dry Weight	184 kg
Fuel System	Electronic fuel injection
Engine Type	V-twin, 4-stroke
Power	129 kW (175 hp) @ 10, 250 rpm
Torque	123 Nm @ 8, 000 rpm
Frame	Chromium-Molybdenum trellis frame, powder coated
Front Brake	2 x Brembo four-piston calipers, 320 mm discs
Rear Brake	220 mm disc, 2-piston caliper
Seat Height	805 mm
