KTM 1190 RC8 R User Manual

11 SERVICE WORK ON THE CHASSIS 180
100752-01
– Check the fluid level.
The fluid level must be between the MIN and MAX markings.
» If the coolant level does not meet specifications:
– Correct the fluid level of the hydraulic clutch. ( p. 180)
11.18 Correcting fluid level of hydraulic clutch
Info
The fluid level rises with increasing wear of the clutch lining disc.
Do not use brake fluid.
– Move the clutch fluid reservoir mounted on the handlebar to a horizontal position.
100753-01
– Remove screw cap with membrane.
– Correct the fuel level.
Guideline
The fluid level must be between the MIN and MAX markings.
Hydraulic fluid (15) ( p. 270)
– Refit the screw cap with the membrane.

KTM 1190 RC8 R Specifications

General

Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Compression Ratio	13.5:1
Transmission	6-speed
Rear Suspension	WP Monoshock
Fuel Tank Capacity	16.5 liters
Dry Weight	184 kg
Fuel System	Electronic fuel injection
Engine Type	V-twin, 4-stroke
Power	129 kW (175 hp) @ 10, 250 rpm
Torque	123 Nm @ 8, 000 rpm
Frame	Chromium-Molybdenum trellis frame, powder coated
Front Brake	2 x Brembo four-piston calipers, 320 mm discs
Rear Brake	220 mm disc, 2-piston caliper
Seat Height	805 mm
