6 CONTROLS 44
6.13.8 Immobilizer
400679-10
The electronic immobilizer secures the vehicle against unauthorized use.
The immobilizer is activated automatically and the engine electronics are locked when the
ignition key is withdrawn.
The red warning lamp flashes at 15 second intervals after one minute.
The red warning lamp can also indicate errors by flashing.
Info
The ignition key contains electronic components. Never attach multiple ignition keys
to a single key ring; this may cause mutual interference and lead to problems.
A lost black ignition key must be deactivated to prevent unauthorized persons from operat-
ing the vehicle.
The second black ignition key is activated when the vehicle is shipped.
Two additional spare ignition keys (key number on the KEYCODECARD) can be ordered from
an authorized KTM workshop, but they must be activated before use.
6.13.9 notes/warnings
401123-01
LOW FUEL appears on the info display if the minimum range falls below the specified value.
Distance 20 km (12.4 mi)

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the KTM 1190 RC8 R and is the answer not in the manual?

KTM 1190 RC8 R Specifications

General IconGeneral
Displacement1195 cc
Bore x Stroke105 mm x 69 mm
Compression Ratio13.5:1
Transmission6-speed
Rear SuspensionWP Monoshock
Fuel Tank Capacity16.5 liters
Dry Weight184 kg
Fuel SystemElectronic fuel injection
Engine TypeV-twin, 4-stroke
Power129 kW (175 hp) @ 10, 250 rpm
Torque123 Nm @ 8, 000 rpm
FrameChromium-Molybdenum trellis frame, powder coated
Front Brake2 x Brembo four-piston calipers, 320 mm discs
Rear Brake220 mm disc, 2-piston caliper
Seat Height805 mm
