KTM 1190 RC8 R User Manual

11 SERVICE WORK ON THE CHASSIS 167
11.1 Raising the rear of the motorcycle with lifting gear
Note
Danger of damage The parked vehicle may roll away or fall over.
– Always place the vehicle on a firm and even surface.
B01321-01
– Insert the adapter into the lifting gear at the rear.
Adapter (61029055120)
Rear wheel stand (61029055400)
– Stand the motorcycle upright, align the lifting gear to the link fork and the adapters,
and raise the motorcycle.
11.2 Removing the rear of motorcycle from the lifting gear
Note
Danger of damage The parked vehicle may roll away or fall over.
– Always place the vehicle on a firm and even surface.
– Secure the motorcycle against falling over.
– Remove the work stand from the rear and lean the vehicle on the side stand.

KTM 1190 RC8 R Specifications

General

Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Compression Ratio	13.5:1
Transmission	6-speed
Rear Suspension	WP Monoshock
Fuel Tank Capacity	16.5 liters
Dry Weight	184 kg
Fuel System	Electronic fuel injection
Engine Type	V-twin, 4-stroke
Power	129 kW (175 hp) @ 10, 250 rpm
Torque	123 Nm @ 8, 000 rpm
Frame	Chromium-Molybdenum trellis frame, powder coated
Front Brake	2 x Brembo four-piston calipers, 320 mm discs
Rear Brake	220 mm disc, 2-piston caliper
Seat Height	805 mm
