KTM 1190 RC8 R User Manual

6 CONTROLS 68
6.13.27 SET‑UP menu
400449-01
Condition
Alternative 1
• The ignition is on.
• The motorcycle is stationary.
• ROAD mode
Alternative 2
• The ignition is on.
• The motorcycle is stationary.
• RACE mode
– Press the button and the button for 3 - 5 seconds.
In the CHANGE MODE menu, you can select between ROAD and RACE mode.
You can set the clock on the SET CLOCK menu.
In the SETTINGS menu, you can set the shift warning light, the lap blank time of the
LAP button, the number of laps, and the reset time of the fuel reserve display.
In the UNITS menu, you can set the units for the speed or distance, temperature and fuel
consumption.
In the OPTIONS menu, you can switch on and off the optional quick shifter, the external
temperature display and the optional tire pressure monitor.
Select EXIT SETUP to close the SET‑UP menu.
The symbol indicates which menu can be activated with the MODE button.
Press the button . The arrow moves up
Press the button . The arrow moves down
Press the button
and the button for
3 - 5 seconds.
No function

KTM 1190 RC8 R Specifications

General

Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Compression Ratio	13.5:1
Transmission	6-speed
Rear Suspension	WP Monoshock
Fuel Tank Capacity	16.5 liters
Dry Weight	184 kg
Fuel System	Electronic fuel injection
Engine Type	V-twin, 4-stroke
Power	129 kW (175 hp) @ 10, 250 rpm
Torque	123 Nm @ 8, 000 rpm
Frame	Chromium-Molybdenum trellis frame, powder coated
Front Brake	2 x Brembo four-piston calipers, 320 mm discs
Rear Brake	220 mm disc, 2-piston caliper
Seat Height	805 mm
