KTM 1190 RC8 R User Manual

6 CONTROLS 58
LastLap shows the lap time of the last lap.
±Last shows the difference between the last lap and the lap before last.
±Best shows the difference between the last lap and the best lap.
If the last lap was the fastest, you see behind ±Best: the Best! symbol in the info display.
Press the button . No function
Press the button . No function
Press the button
and the button for
3 - 5 seconds.
The display changes to the SET‑UP menu
Press the MODE but-
ton for 3 - 5 sec-
onds.
All values in RACE mode are reset (except RACEODO)
Press the MODE but-
ton briefly.
Next display mode
6.13.19 Maximum lap speed menu, TOPSPEED
401144-01
Condition
Alternative 1
• The ignition is on.
• The motorcycle is stationary.
• RACE mode
Alternative 2
• The ignition is on.
• The motorcycle is being ridden.
• RACE mode
– Press the MODE button briefly and repeatedly until TOPSPEED appears at the top left of
the info display.
TOPSPEED shows the highest lap speed.

KTM 1190 RC8 R Specifications

General

Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Compression Ratio	13.5:1
Transmission	6-speed
Rear Suspension	WP Monoshock
Fuel Tank Capacity	16.5 liters
Dry Weight	184 kg
Fuel System	Electronic fuel injection
Engine Type	V-twin, 4-stroke
Power	129 kW (175 hp) @ 10, 250 rpm
Torque	123 Nm @ 8, 000 rpm
Frame	Chromium-Molybdenum trellis frame, powder coated
Front Brake	2 x Brembo four-piston calipers, 320 mm discs
Rear Brake	220 mm disc, 2-piston caliper
Seat Height	805 mm
