KTM 1190 RC8 R User Manual

10 TUNING THE CHASSIS 140
Info
Turn clockwise to increase preload, turn counterclockwise to reduce spring
preload.
100689-10
–
Tighten screw

.
Guideline
Remaining frame bolts M5 5 Nm (3.7 lbf ft)
10.10 Steering damper
B01314-01
The steering damper suppresses shocks to the steering arising from acceleration on uneven
ground at high speed or when the load is temporarily taken from the front wheel.
The steering damper is adjusted to suit the riding style and the road conditions. For high
speeds, a setting with high damping can be chosen to make the best possible use of the
steering damper function. In slow, tight bends, intensive damping can negatively affect
handling and steering precision, so the damping should be set to low.

KTM 1190 RC8 R Specifications

General

Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Compression Ratio	13.5:1
Transmission	6-speed
Rear Suspension	WP Monoshock
Fuel Tank Capacity	16.5 liters
Dry Weight	184 kg
Fuel System	Electronic fuel injection
Engine Type	V-twin, 4-stroke
Power	129 kW (175 hp) @ 10, 250 rpm
Torque	123 Nm @ 8, 000 rpm
Frame	Chromium-Molybdenum trellis frame, powder coated
Front Brake	2 x Brembo four-piston calipers, 320 mm discs
Rear Brake	220 mm disc, 2-piston caliper
Seat Height	805 mm
