KTM 1190 RC8 R User Manual

10 TUNING THE CHASSIS 139
Info
The spring preload defines the initial situation of the spring process on the shock absorber.
The best spring preload setting is achieved when it is set for the weight of the rider and that of any baggage and a passenger, thus
ensuring an ideal compromise between maneuverability and stability.
100689-10
– Take the weight off the rear wheel and swingarm.
Info
The spring preload can be adjusted correctly only if the rear wheel and the
swingarm are fully relieved of weight.
–
Loosen screw

by two turns.
100690-01
– Turn the adjusting ring counterclockwise with the wrench from the tool kit until the
spring is no longer under tension.
Hook wrench (69012022000)
Extension (60012060000)
– Turn the adjusting ring clockwise and tension it to the specified value.
Guideline
Spring preload
Comfort 9 mm (0.35 in)
Standard 9 mm (0.35 in)
Sport 9 mm (0.35 in)
Full payload 10 mm (0.39 in)

KTM 1190 RC8 R Specifications

General

Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Compression Ratio	13.5:1
Transmission	6-speed
Rear Suspension	WP Monoshock
Fuel Tank Capacity	16.5 liters
Dry Weight	184 kg
Fuel System	Electronic fuel injection
Engine Type	V-twin, 4-stroke
Power	129 kW (175 hp) @ 10, 250 rpm
Torque	123 Nm @ 8, 000 rpm
Frame	Chromium-Molybdenum trellis frame, powder coated
Front Brake	2 x Brembo four-piston calipers, 320 mm discs
Rear Brake	220 mm disc, 2-piston caliper
Seat Height	805 mm
