KTM 1190 RC8 R User Manual

23 TECHNICAL DATA 256
Screw, gear sensor M5 6 Nm (4.4 lbf ft) Loctite
®
243™
Screw, pulse generator M5 6 Nm (4.4 lbf ft) Loctite
®
243™
Camshaft drive sprocket bolt M6 14 Nm (10.3 lbf ft) –
Freewheel ring bolt M6 – 10.9 15 Nm (11.1 lbf ft) Loctite
®
648™
Nut, cylinder head M6 9 Nm (6.6 lbf ft) –
Plug, vacuum connection M6 5 Nm (3.7 lbf ft) Loctite
®
243™
Remaining engine screws M6 10 Nm (7.4 lbf ft) –
Screw, camshaft bearing support M6 – 10.9 10 Nm (7.4 lbf ft) –
Screw, clutch cover M6 10 Nm (7.4 lbf ft) –
Screw, clutch spring M6 12 Nm (8.9 lbf ft) –
Screw, coolant connection on cylinder
head
M6 10 Nm (7.4 lbf ft) –
Screw, engine case M6x60 10 Nm (7.4 lbf ft) –
Screw, engine case M6x80 10 Nm (7.4 lbf ft) –
Screw, engine case M6x90 10 Nm (7.4 lbf ft) –
Screw, freewheel holder M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, locking lever M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, oil pump cover M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, shift drum locating M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, shift lever M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, starter motor M6 10 Nm (7.4 lbf ft) –
Screw, stator M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, valve cover M6 10 Nm (7.4 lbf ft) –
Screw, water pump cover M6 10 Nm (7.4 lbf ft) –
Screw, water pump wheel M6 10 Nm (7.4 lbf ft) Loctite
®
243™

KTM 1190 RC8 R Specifications

General

Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Compression Ratio	13.5:1
Transmission	6-speed
Rear Suspension	WP Monoshock
Fuel Tank Capacity	16.5 liters
Dry Weight	184 kg
Fuel System	Electronic fuel injection
Engine Type	V-twin, 4-stroke
Power	129 kW (175 hp) @ 10, 250 rpm
Torque	123 Nm @ 8, 000 rpm
Frame	Chromium-Molybdenum trellis frame, powder coated
Front Brake	2 x Brembo four-piston calipers, 320 mm discs
Rear Brake	220 mm disc, 2-piston caliper
Seat Height	805 mm
