23 TECHNICAL DATA 257
Stud, chain shaft M6 8 Nm (5.9 lbf ft) –
Vacuum connection M6 2.5 Nm (1.84 lbf ft) Loctite
®
243™
Oil nozzle M6x0.75 4 Nm (3 lbf ft) Loctite
®
243™
Plug, crankshaft retainer M8 15 Nm (11.1 lbf ft) –
Screw, camshaft bearing support M8 – 10.9 Step 1
10 Nm (7.4 lbf ft)
Step 2
18 Nm (13.3 lbf ft)
–
Screw, camshaft bearing support M8 – 10.9 Step 1
8.5 Nm (6.27 lbf ft)
Step 2
14.5 Nm (10.7 lbf ft)
Only applies when using:
Hex key bit (61229025000)
Screw, engine case M8 18 Nm (13.3 lbf ft) –
Screw, heat exchanger M8 15 Nm (11.1 lbf ft) –
Screw, timing chain guide rail M8 15 Nm (11.1 lbf ft) Loctite
®
243™
Screw, timing chain tensioning rail M8 15 Nm (11.1 lbf ft) Loctite
®
243™
Stud, exhaust flange M8 10 Nm (7.4 lbf ft) –
Screw, engine bearer M10 45 Nm (33.2 lbf ft) –
Oil pressure sensor M10x1 10 Nm (7.4 lbf ft) –
Plug, cam lever axis M10x1 15 Nm (11.1 lbf ft) –
Plug, clutch lubrication M10x1 10 Nm (7.4 lbf ft) –
Screw, conrod bearing M10x1 Step 1
25 Nm (18.4 lbf ft)
Step 2
30 Nm (22.1 lbf ft)
Step 3
90°
–

KTM 1190 RC8 R Specifications

General

Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Compression Ratio	13.5:1
Transmission	6-speed
Rear Suspension	WP Monoshock
Fuel Tank Capacity	16.5 liters
Dry Weight	184 kg
Fuel System	Electronic fuel injection
Engine Type	V-twin, 4-stroke
Power	129 kW (175 hp) @ 10, 250 rpm
Torque	123 Nm @ 8, 000 rpm
Frame	Chromium-Molybdenum trellis frame, powder coated
Front Brake	2 x Brembo four-piston calipers, 320 mm discs
Rear Brake	220 mm disc, 2-piston caliper
Seat Height	805 mm
