10 TUNING THE CHASSIS 147
B00561-10
Remove screws
.
B00562-10
Position the footrest bracket with spacers
and screws.
Guideline
Standard Upper position
Info
The adjustable footrest bracket enables a more comfortable lower footrest posi-
tion or a sporting upper footrest position.
B00561-01
Mount and tighten the screws.
Guideline
Screw, front footrest bracket M8 25 Nm
(18.4 lbf ft)
Loctite
®
243™
