11 SERVICE WORK ON THE CHASSIS 177
700303-01
– Shift into neutral.
–
Pull the lower chain section with specified weight

.
Guideline
Weight, chain wear measurement 15 kg (33 lb.)
–
Measure the distance

of 18 chain links in the lower chain section.
Info
Chain wear is not always even, so you should repeat this measurement at differ-
ent chain positions.
Maximum distance

at the longest
chain section
272 mm (10.71 in)
»
If distance

is greater than the specified measurement:
– Change the power set.
Info
When the chain is replaced, the rear sprocket and engine sprocket
should also be changed.
A new chain wears out faster on old, worn sprockets.
For safety reasons, the chain has no chain joint.

KTM 1190 RC8 R Specifications

General

Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Compression Ratio	13.5:1
Transmission	6-speed
Rear Suspension	WP Monoshock
Fuel Tank Capacity	16.5 liters
Dry Weight	184 kg
Fuel System	Electronic fuel injection
Engine Type	V-twin, 4-stroke
Power	129 kW (175 hp) @ 10, 250 rpm
Torque	123 Nm @ 8, 000 rpm
Frame	Chromium-Molybdenum trellis frame, powder coated
Front Brake	2 x Brembo four-piston calipers, 320 mm discs
Rear Brake	220 mm disc, 2-piston caliper
Seat Height	805 mm
