14 ELECTRICAL SYSTEM 203

B01328-10

Main work

–

Disconnect negative cable



from the battery.

B01329-10

– Remove the cover of the positive terminal.

–

Disconnect positive cable



from the battery.

B01329-11

–

Remove screws



.

–

Remove holder



.

– Lift out the battery.
