KTM 1190 RC8 R User Manual

14 ELECTRICAL SYSTEM 207
M00702-10
Main work
– Connect the battery charger to the battery. Switch on the battery charger.
Battery charger (58429074000)
You can also use the battery charger to test the rest potential and start potential of the
battery, and to test the alternator. With this device, you cannot overcharge the battery.
Info
Never remove lid

.
Charge the battery to a maximum of 10% of the capacity specified on battery
housing

.
– Switch off the battery charger after charging and disconnect from the battery.
Guideline
The charge current, charge voltage and charge time must not be exceeded.
Charge the battery regularly when the
motorcycle is not in use
3 months
– Connect the negative cable with the battery.
Guideline
Screw, battery terminal M6 4.5 Nm
(3.32 lbf ft)
Finishing work
– Fit the seat. ( p. 170)
– Set the clock with SET CLOCK. ( p. 96)

KTM 1190 RC8 R Specifications

General

Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Compression Ratio	13.5:1
Transmission	6-speed
Rear Suspension	WP Monoshock
Fuel Tank Capacity	16.5 liters
Dry Weight	184 kg
Fuel System	Electronic fuel injection
Engine Type	V-twin, 4-stroke
Power	129 kW (175 hp) @ 10, 250 rpm
Torque	123 Nm @ 8, 000 rpm
Frame	Chromium-Molybdenum trellis frame, powder coated
Front Brake	2 x Brembo four-piston calipers, 320 mm discs
Rear Brake	220 mm disc, 2-piston caliper
Seat Height	805 mm
