KTM 1190 RC8 R User Manual

14 ELECTRICAL SYSTEM 216
700299-01
–
Unplug connector

.
–
Push off the retaining clamp

on both sides, squeeze and fold to the side.
– Remove headlight bulb.
– Position the new headlight bulb in the headlight housing.
Guideline
Insert the headlight bulb so that the lug is positioned in the cut-out.
Low beam / high beam (H7 / base PX26d) ( p. 261)
– Position the retaining clamp.
– Plug in the connector.

KTM 1190 RC8 R Specifications

General

Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Compression Ratio	13.5:1
Transmission	6-speed
Rear Suspension	WP Monoshock
Fuel Tank Capacity	16.5 liters
Dry Weight	184 kg
Fuel System	Electronic fuel injection
Engine Type	V-twin, 4-stroke
Power	129 kW (175 hp) @ 10, 250 rpm
Torque	123 Nm @ 8, 000 rpm
Frame	Chromium-Molybdenum trellis frame, powder coated
Front Brake	2 x Brembo four-piston calipers, 320 mm discs
Rear Brake	220 mm disc, 2-piston caliper
Seat Height	805 mm
