23 TECHNICAL DATA 260
Rear 220 mm (8.66 in)
Brake discs - wear limit
Front 4.5 mm (0.177 in)
Brake disc - wear limit
Rear 4.5 mm (0.177 in)
Tire air pressure, solo
Front 2.5 bar (36 psi)
Rear 2.5 bar (36 psi)
Tire air pressure with passenger / full payload
Front 2.5 bar (36 psi)
Rear 2.9 bar (42 psi)
Secondary drive 17:38
Chain 5/8 x 5/16” X‑ring
Steering head angle 66.7°
Wheelbase 1,425 mm (56.1 in)
Seat height, unloaded
Lower frame rear position 805 mm (31.69 in)
Upper frame rear position 825 mm (32.48 in)
Ground clearance, unloaded 110 mm (4.33 in)
Weight without fuel approx. 184 kg (406 lb.)
Maximum permissible front axle load 150 kg (331 lb.)
Maximum permissible rear axle load 240 kg (529 lb.)
Maximum permissible total weight 380 kg (838 lb.)

KTM 1190 RC8 R Specifications

General

Displacement	1195 cc
Bore x Stroke	105 mm x 69 mm
Compression Ratio	13.5:1
Transmission	6-speed
Rear Suspension	WP Monoshock
Fuel Tank Capacity	16.5 liters
Dry Weight	184 kg
Fuel System	Electronic fuel injection
Engine Type	V-twin, 4-stroke
Power	129 kW (175 hp) @ 10, 250 rpm
Torque	123 Nm @ 8, 000 rpm
Frame	Chromium-Molybdenum trellis frame, powder coated
Front Brake	2 x Brembo four-piston calipers, 320 mm discs
Rear Brake	220 mm disc, 2-piston caliper
Seat Height	805 mm
