Kyocera ECOSYS MA4500x User Manual

8-4
Setup and Registration (System Menu) > System Menu
Language Select the language displayed on the message display. page 8-28
Default Screen Select the screen appearing right after start-up (default screen). page 8-28
Sound Set options for buzzer sound during the machine operations. page 8-28
Display Bright. Set the brightness of the message display. page 8-28
Cassette 1 (to 5) Set.
(Cassette 1 (to 5) Settings)
Select type of paper in Cassette 1 (to 5). page 8-32
MP Tray Set. (MP Tray Settings) Select type of paper in multi purpose tray. page 8-32
Orig./Paper Set. Configure settings for originals. page 8-29
Preset Limit Restrict the number of copies that can be made at one time. page 8-33
Measurement Select inch or metric for the unit for paper dimensions. page 8-33
Error Handling Select whether to cancel or continue the job when error has occurred. page 8-34
Date Setting Configure settings related to the date and time. page 8-34
Timer Setting Configure settings related to the time. page 8-35
Function Defaults Defaults are the values automatically set after the warm-up is
completed or the [Reset] key is selected.
Set the defaults for available settings such as copying and sending. Setting
the frequently-used values as defaults makes subsequent jobs easier.
page 8-37
Login Operation Select the screen to enter the login user name and password when
logging in.
page 8-39
RAM Disk Mode A RAM disk can be created and its size can be set. page 8-40
Optional Memory When optional memory is installed, select the memory allocation
scheme based on the application in which you are using the
equipment.
page 8-40
Disp. Status/Log Set the display method of the Status/Log. page 8-40
Keyboard Type Select the type of keyboard that you want to use. page 8-41
Low Toner Alert Set the amount of remaining toner to notify the administrator when
to order a toner when the toner is running low.
page 8-41
Show PowerOffMsg Set the mode whether display a confirmation message in power
supply off.
page 8-41
EnergySaver Set. Select the method of recovery from energy saver. page 8-42
Msg Banner Print Set whether the confirmation screen appears before each sheet is
printed when printing multiple banner sheets.
page 8-42
Copy Configures settings for copying functions. page 8-43
Printer Printing from computers, settings are generally made on the
application software screen. However, the following settings are
available for configuring the defaults to customize the machine.
page 8-44
Send Configures settings for sending functions. page 8-46
FAX Configures settings for fax functions.
FAX Operation Guide
—
Document Box Configures settings related to the Custom Box, Job Box, Sub Address
Box and Polling Box.
FAX Operation Guide
page 8-48
Item Description Reference
Page

Kyocera ECOSYS MA4500x Specifications

General

N-up printing	2, 4, 6, 8, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.3 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Duplex print speed (black, normal quality, A4/US Letter)	22.5 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	6 s
Copy speed (black, normal quality, A4)	45 cpm
Scan to	E-mail, FTP, Fax, File, Image, Memory Card, PC, SMB, TWAIN, USB, WIA
Scan drivers	TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Maximum scan area	210 x 297 mm
Scan speed (black)	60 ppm
Scan speed (color)	40 ppm
Image formats supported	JPEG, TIFF
Duplex scan speed (black)	26 ppm
Duplex scan speed (color)	17 ppm
Document formats supported	PDF, XPS
Optical scanning resolution (black)	600 x 600 ppi
Optical scanning resolution (color)	300 x 300 ppi
Faxing	No
Printer fonts	Barcode, Bitmap, PCL
Printing colors	Black
Duplex functions	Copy, Print, Scan
Country of origin	Vietnam
Maximum duty cycle	150000 pages per month
Recommended duty cycle	3000 - 15000 pages per month
Replacement cartridges	TK-3400
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PCL XL, PDF 1.4
Total input capacity	600 sheets
Total output capacity	250 sheets
Maximum input capacity	2600 sheets
Paper tray 1 input capacity	500 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Custom media width	140 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	210 - 356 mm
Paper tray media types	Banner, Letterhead, Plain paper, Pre-Printed, Thicker paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-Purpose Tray media weight	60 - 220 g/m²
Optional connectivity	Ethernet, Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Kyocera Mobile Print, Mopria Print Service
Processor family	ARM Cortex-A5
Compatible memory cards	SD
Maximum internal memory	3000 MB
Sound pressure level (standby)	30 dB
Sound pressure level (printing)	54 dB
Display	LCD
Control type	Buttons
Product color	Black, White
Market positioning	Business
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	Blablabla W
Power consumption (off)	0.1 W
Power consumption (ready)	55 W
Power consumption (sleep)	0.5 W
Power consumption (copying)	585 W
Power consumption (standby)	38 W
Power consumption (printing)	602 W
Energy Star Typical Electricity Consumption (TEC)	0.62 kWh/week
Mac operating systems supported	Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura
Package depth	570 mm
Package width	607 mm
Package height	695 mm
Package weight	30000 g
Cables included	AC
Included cartridge capacity (black)	6000 pages
Operating altitude	0 - 3500 m
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	15 - 80 %
Sustainability certificates	REACH, RoHS, Turkish Environment Label

Weight and Dimensions

Depth	476 mm
Width	475 mm
Height	575 mm
