8400 HighLine | Parameter setting & configuration
Motor control (MCTRL)
Servo control (SC)
154 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
5.7.3.2 Optimise speed controller
The speed controller is in the form of a PID controller with an additional differential speed-
setpoint gain. For optimum behaviour, the PID speed controller has to be optimised and
the overall mass inertia of the drive train has to be determined.
 In the Lenze setting, the configuration of the speed controller provides robustness and
moderate dynamics.
Speed controller gain Vp
Gain Vp (C00070/2
) of the speed controller is specified in a scaled representation which
permits similar parameter setting that is almost independent of the power of the motor or
the inverter:
If the rated data of the motor and the mass inertia of the drive system are known, we
recommend the following setting:
[5-17] Recommendation for the setting of the gain of the speed controller
Parameter Info Lenze setting
Value Unit
C00070/2 SC: Vp speed controller 6.00
C00071/2
SC: Ti speed controller 50.0 ms
C00072
SC: Tdn speed controller 0.00 ms
V
P
= Gain of the speed controller (C00070/2)
M
N
= Rated motor torque
n
N
= Rated motor speed
V
P
= Gain of the speed controller (C00070/2)
T
M
= Time constant for the acceleration of the motor
M
N
= Rated motor torque
n
N
= Rated motor speed
J
drive, total
= Total moment of inertia of the drive
V
P
M
N
n
N
--------
%[]=
V
P
1,5 ... 3
T
M
s[]
001s[],
--------------------
⋅≈
T
M
s[]
2 π n
N
min
1–
[]⋅⋅
M
N
Nm[]60⋅
--------------------------------------------
J
Antrieb gesamt(,)
kgm
2
[]⋅=
M
N
Nm[]
P
N
W[]60⋅
2 π n
N
min
1–
[]⋅⋅
--------------------------------------------=
