8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C01245
C01245
C01251
C01252
Parameter | Name:
C01245 | MCK: Target detection - positions
Data type: INTEGER_32
Index: 23330
d
= 5B22
h
As of version 02.00.00
Position parameter for comparison with target positions
Positioning
Setting range (min. value | unit | max. value)
0.0000 units 214748.3647
Subcodes Lenze setting Info
C01245/1 1.0000 units MCK: Target position window
• Window around the target position for comparison
with the actual position to see whether the drive is in
target.
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10000
Parameter | Name:
C01251 | MCK: Accelerations stop
Data type: INTEGER_32
Index: 23324
d
= 5B1C
h
Acceleration parameter for stop
Stop
Setting range (min. value | unit | max. value)
-214748.3647 units/s2 214748.3647
Subcodes Lenze setting Info
C01251/1 720.0000 units/s2 Stop: Decel.
• Deceleration for setpoint speed ramp-down to
standstill.
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10000
Parameter | Name:
C01252 | MCK: S-ramp times stop
Data type: UNSIGNED_16
Index: 23323
d
= 5B1B
h
S-ramp times for stop
•Setting "0 s" ≡ no rounding
Stop
Setting range (min. value | unit | max. value)
0.000 s 10.000
Subcodes Lenze setting Info
C01252/1 0.000 s Stop: S-ramp time
• S-ramp time for setpoint speed ramp-down to
standstill.
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1000
