Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010 L 665
8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00488
C00488
C00490
C00495
Parameter | Name:
C00488 | L_JogCtrlEdgeDetect_1
Data type: UNSIGNED_8
Index: 24087
d
= 5E17
h
As of version 02.00.00
FB L_JogCtrlExtension_1
: Signal methodology
• Selection whether the corresponding function is to be activated by edge or level.
Selection list
0 Level
1Edge
Subcodes Lenze setting Info
C00488/1 0: Level InputSens.SlowDown1
• Selection of edge or level for starting slow-down
function 1
C00488/2 0: Level InputSens.Stop1
• Selection of edge or level for stop function 1
C00488/3 0: Level InputSens.SlowDown2
• Selection of edge or level for starting slow-down
function 2
C00488/4 0: Level InputSens.Stop2
• Selection of edge or level for stop function 2
C00488/5 0: Level InputSens.SlowDown3
• Selection of edge or level for starting slow-down
function 3
C00488/6 0: Level InputSens.Stop3
• Selection of edge or level for stop function 3
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C00490 | Position encoder selection
Data type: UNSIGNED_8
Index: 24085
d
= 5E15
h
Selection of the feedback system for the generation of the actual position on the load
Encoder/feedback system
Selection list (Lenze setting printed in bold) Info
0 No sensor No encoder available on the load
1 Sensor signal FreqIn12 Position encoder signal is fed via digital inputs DI1 and
DI2
2 Encoder signal FreqIn67 Position encoder signal is fed via digital inputs DI6 and
DI7
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
Parameter | Name:
C00495 | Speed sensor selection
Data type: UNSIGNED_8
Index: 24080
d
= 5E10
h
Selection of the feedback system for the actual speed for motor control and display
Encoder/feedback system
Selection list (Lenze setting printed in bold) Info
0 No sensor No encoder available for the actual speed detection
1 Sensor signal FreqIn12 Speed encoder signal is fed via digital inputs DI1 and DI2
2 Encoder signal FreqIn67 Speed encoder signal is fed via digital inputs DI6 and DI7
; Read access ; Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1
