Lenze 8400 HighLine C Series User Manual

8400 HighLine | Parameter setting & configuration
Parameter reference
Parameter list | C00029
596 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
C00029
C00033
C00034
C00036
Parameter | Name:
C00029 | AINx: Input current
Data type: INTEGER_16
Index: 24546
d
= 5FE2
h
Display of the input current at the analog inputs
• When the corresponding analog input is configured for current measurement (C00034/x
=1 or 2).
•When C00034/x
is set = 2 (4 ... 20 mA), 0 ... 16 mA is displayed.
Analog terminals
Display range (min. value | unit | max. value)
0.00 mA 20.00
Subcodes Info
C00029/1 AIN1: Input current
C00029/2 AIN2: Input current
; Read access  Write access  CINH  PLC STOP ; No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00033 | AINx: Output value
Data type: INTEGER_16
Index: 24542
d
= 5FDE
h
Display of the output value in percent of the analog input amplifier
• 100 % ≡ 16384 ≡ +10 V / +20 mA
Analog terminals
Display range (min. value | unit | max. value)
-199.99 % 199.99
Subcodes Info
C00033/1 AIN1: Output value
C00033/2 AIN2: Output value
; Read access  Write access  CINH  PLC STOP ; No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00034 | AINx: Configuration
Data type: UNSIGNED_8
Index: 24541
d
= 5FDD
h
Configuration of the analog inputs for current or voltage measurement
Analog terminals
Selection list Info
0 -10V..+10V Input signal is the voltage signal -10 V ... +10 V
• -10 V ... +10 V ≡ -100 % ... +100 %
1 0mA..20mA Input signal is the current signal 0 mA ... 20 mA
•0mA...20mA ≡ 0%...+100%
2 4mA..20mA Input signal is the current signal 4 mA ... 20 mA
•4mA...20mA ≡ 0%...+100%
• The current loop is monitored for open circuit
(I < 4 mA) by the device.
Subcodes Lenze setting Info
C00034/1 0: -10V..+10V AIN1: Config.
C00034/2 0: -10V..+10V AIN2: Config.
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00036 | DCB: Current
Data type: INTEGER_16
Index: 24539
d
= 5FDB
h
Current value in [%] for DC-injection braking
•100% ≡ Imax in motor mode (C00022
)
Setting range (min. value | unit | max. value) Lenze setting
0.00 % 200.00 50.00 %
; Read access ; Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
