9300 Servo PLC
Connection
3-29

9300ServoPLC EN 1.4
Correction value phase controller
Code LCD
Possible settings
IMPORTANT
C
o
d
e
C
Lenze Choice
O
C0363 Sync corr 1 0{1}5CAN Sync correction
Change correction value until
CAN_nSyncDeviation has reached a
minimum.
1=0.2µs/ms
2=0.4µs/ms
3=0.6µs/ms
4=0.8µs/ms
5=1.0µs/ms
CAN sync reaction
Code LCD
Possible settings
IMPORTANT
C
o
d
e
C
Lenze Choice
O
C0366 Sync Response 1 0 no sync response
1 sync response
CAN sync. response
When C366 = 1, the controller
reacts on a sync telegram by
sending the CAN1_OUT object.
CAN Sync identifier
Transmission or receive identifier of the sync telegram.
Code LCD
Possible settings
IMPORTANT
C
o
d
e
C
Lenze Choice
O
C0367 Sync Rx ID 128 1 {1} 256 CANSyncRxIdentifier
Receive identifier of the sync
telegram.
C0368 Sync Tx ID 128 1 {1} 256 CANSyncTxIdentifier
Transmit identifier of the sync
telegram.
CAN Sync Tx transmit cycle
Code LCD
Possible settings
IMPORTANT
C
o
d
e
C
Lenze Choice
O
C0369 Sync Tx Time 0 0 {1} 65000 CAN sync transmit telegram
cycle time
A sync telegramwith the identifier
of C0368 is sent with the set cycle
time (C369 = 0, off).
