9300 Servo PLC
System blocks
2.13 Internal motor control (MCTRL_MotorControl)
2-62
9300ServoPLC EN 1.4
2.13.13.9 Resolver monitoring for wire breakage Sd2
(MCTRL_bResolverFault_b)
Purpose
• Motor protection
• Monitors the cable and the resolver for wire breakage.
Function
Warning!
During commissioning this monitoring should not be switched off, sincethe machinemay reachvery
high speeds (potential destruction of the motor and the driven machine)in the event of a fault (e.g.
system cables disconnected or incorrectly bolted). The same applies if this monitoring is changed
to WARNING. The possibility of disconnection should only be used if the monitoring reacts without
obvious reasons (very long cables, strong noises of other devices).
• This monitoring is activated automatically if the resolver is selected as actual speed encoder
(C0025).
• This monitoring is deactivated automatically if another actual speed encoder is selected.
Stop!
If there is a fault in the actual speed detection, it is not ensured that the monitoring reacts to
overspeed NMAX.
Features:
• LECOM no.: 82, 2082
• Reaction: TRIP, WARNING or OFF
