9300 Servo PLC
System blocks
2.4 Automation interface (AIF3_IO_AutomationInterface)
2-16

9300ServoPLC EN 1.4
VariableName DataType SignalType Address DIS DIS format Note
AIF3_nInW1_a Integer analog %IW43.0 +16384 = +100 %
AIF3_nInW2_a Integer analog %IW43.1 +16384 = +100 %
AIF3_nInW3_a Integer analog %IW43.2 +16384 = +100 %
AIF3_nInW4_a Integer analog %IW43.3 +16384 = +100 %
AIF3_bInB0_b Bool binary %IX43.0.0
.. .. .. ..
.. .. .. ..
AIF3_bInB15_b Bool binary %IX43.0.15
AIF3_bInB16_b Bool binary %IX43.1.0
.. .. .. ..
.. .. .. ..
AIF3_bInB31_b Bool binary %IX43.1.15
AIF3_dnInD1_p Double integer position %ID43.0 65536 = 1 revolution
Function
Theinputsignalsofthe8byteuserdataoftheAIF-objectareconvertedintocorrespondingsignal
types.
Bytes 1-2 and bytes 3-4
• Byte 1, 2 and byte 3, 4 can be used as binary information (2 x 16 bit)
• Byte 1, 2 and byte 3, 4 can be used as double word (32 bit)
Byte 5 and 6
Bytes 5, 6 form the signal for
AIF3_nInW3_a .
Bytes 7, 8
Bytes 7, 8 form the signal for
AIF3_nInW4_a .
Address range from byte 1 - 7
Byte Address
1, 2 %IB43.0 and %IB43.1
3, 4 %IB43.2 and %IB43.3
5, 6 %IB43.4 and %IB43.5
7, 8 %IB43.6 and %IB43.7
