Lenze 9300 vector Series Mounting Instructions

Electrical installation
Standard devices in the power range 0.37 ... 11 kW
Mains connection: Fuses and cable cross−sections
5

171
EDKVF9333V DE/EN/FR 7.2
Operation at rated power
9300 Rated fuse current Cable cross−section FI
1)
Fuse Circuit−breaker Laying system L1, L2, L3, PE
B2 C
Type [A] [A] [mm
2
] [mm
2
] [mA]
Operation without mains choke/mains filter
EVF9321−xV
6 C6, B6
2)
1 1
300
EVF9322−xV 6 C6, B6
2)
1 1
EVF9323−xV 10 B10 1.5 1
EVF9325−xV 25 B20 4 2.5
Operation with mains choke/mains filter
EVF9321−xV 6 C6, B6
2)
1 1
300
EVF9322−xV 6 C6, B6
2)
1 1
EVF9323−xV 10 B10 1.5 1
EVF9324−xV 10 B10 1.5 1
EVF9325−xV 20 B16 2.5 2.5
EVF9326−xV 32 B25 ˘ 4
1)
Universal current−sensitive earth−leakage circuit breaker
2)
For short−time mains interruptions, use circuit breakers with tripping characteristic "C"
Operation with increased rated power
9300 Rated fuse current Cable cross−section FI
1)
Fuse Circuit−breaker Laying system L1, L2, L3, PE
B2 C
Type [A] [A] [mm
2
] [mm
2
] [mA]
Operation with mains choke/mains filter
EVF9321−xV
6 C6, B6
2)
1 1
300
EVF9322−xV 6 C6, B6
2)
1 1
EVF9323−xV 10 B10 1.5 1
EVF9324−xV 10 B10 1.5 1
EVF9325−xV 20 B16 2.5 2.5
1)
Universal current−sensitive earth−leakage circuit breaker
2)
For short−time mains interruptions, use circuit breakers with tripping characteristic "C"
