Electrical installation
Standard devices in the power range 0.37 ... 11 kW
Mains connection: Fuses and cable cross−sections
5
172
EDKVF9333V DE/EN/FR 7.2
Installation to UL
Supply conditions
Range Description
Fuses l Only in accordance with UL 248
l System short−circuit current up to 5000 A
rms
: All classes are permissible
l System short−circuit current up to 50000 A
rms
: Only classes "CC", "J", "T" or "R" permissible
Cables l Only in accordance with UL
l The cable cross−sections specified in the following apply under the following conditions:
– Conductor temperature < 60 °C
– Ambient temperature < 40 °C
Observe all national and regional regulations!
Operation at rated power
9300 Rated fuse current Cable cross−section
Fuse L1, L2, L3, PE
Type [A] [AWG]
Operation without mains choke/mains filter
EVF9321−xV
6 18
EVF9322−xV 6 18
EVF9323−xV 10 16
EVF9325−xV 25 10
Operation with mains choke/mains filter
EVF9321−xV 6 18
EVF9322−xV 6 18
EVF9323−xV 10 16
EVF9324−xV 10 16
EVF9325−xV 25 10
EVF9326−xV 25 10
Max. connection cross−section of the terminal strip: AWG 12, with pin−end connector AWG 10
