● Images indicated by [○] in the figure are
a composite, and hence some areas may
be difficult to see.
■ Wide front view
A
Area displayed on the screen
B
Objects not displayed on the screen
Areas close to both corners of the bump-
ers will not appear on the screen.
INFORMATION
● The area covered by the camera is limited. Objects that are close to either corner of
the bumper or under the bumper cannot be displayed on the screen.
● The depth perception of the image displayed on the screen differs to the actual
distance.
● The wide front view camera uses a special lens, so the depth perception of the image
displayed on the screen differs to the actual distance.
8-2. Panoramic view monitor
324
