10-54
Using the LI-8150 Multiplexer
Click on Values by Port to plot records by port, on left, right, and X axes. Choose
the Port (Chamber) whose records you want to plot, and then select the variable to
plot on each axis. Click Plot. To automatically scale the left and/or right axes,
click on Chart Options. Enable automatic scaling, and set the maximum and
minimum values for the axes, if desired. To view the selected Observations in
tabular format, click on View Table. Click Clear Chart to remove all data from the
chart.
