Support for additional DALI Sensors
Support for the ThebenHTS PlanoSpot 360 DALI multi-sensor was added.
Change the DALI Short Address
If required the DALI short address, which was assigned to a DALI device by the L-DALI,
can be changed via the Web-UI (see Section 5.3.4.9).
Generic Scheduler
Generic schedulers – like generic trends and alarms – can now be created, that are neither
CEA-709 nor BACnet objects. Generic schedulers appear next to the generic alarm folder
and are ready-to-use on any device. This is beneficial for creating technology-independent
applications. Generic schedulers can write to any technology as well as data point favorites
and are the ideal solution, if configured via LWEB-900 only. For more information on
creating generic schedulers refer to Section 7.10.
Web Interface
The Web interface of the device offers a number of new features:
Live update of values in the data point list. This allows monitoring values without
repeated pressing of reload. Data point structures can be expanded or collapsed for
better overview.
Breadcrumb navigation has been added to the data point list. This gives faster access to
sub-folders.
A new firmware upgrade menu on the Web interface allows online checking for
firmware updates and upgrading by selecting a local firmware file. All this is possible
without starting the Configurator.
The trend overview page displays current trend log states and provides controls for
easy trend data upload in CSV format.
The DALI group page allows switching groups on and off to test the group assignment.
Application Objects
Application objects such as math objects, e-mail templates, and alarm logs can now be
organized in folders. Copy and paste of application objects between Configurators has been
improved. Math objects now allow single constants and single variable assignments, such as
“=5” or “=v1”. Input variables can be configured to trigger a new calculation or not.
