The YAG laser light and its reflections are potential hazards to the eye. Use extreme caution when
operating the system with the covers opened or removed. The covers contain the beam and reflections
safely within the console. Only those persons required should be present during servicing and eye
protection that safely attenuates the YAG wavelength should be worn by all those present.
5.2 INTERIOR ACCESS & PARTS LOCATION
Interior access is gained through the front cover (door), which is hinged on the right side. Once the front cover
is opened, the top cover can be removed. Once the top cover is removed the two side panels can be removed.
Open the front cover to access the DC power supply (mounted inside the door), to access the Controller PCB,
or to remove the top cover or either side cover.
To open the front cover, insert a special tool (such as a hex key) through the hole on the bottom left of the front
cover. Push up on the tab inside the hole to release the cover (it is hinged on the right side). Refer to Fig. 5.1.
