7528%/(6+227,1* 9HUVD3XOVHPowerSuite6HULHV6HUYLFH0DQXDO
5(9%
TP7 FGND Ground reference point
TP8 FGND Ground reference point
AC CONTROL PCB:
TP1 24RET 24V return
TP2 C-
ATTENUATOR PCB:
TP1 DGND Digital ground reference point
OPTICS BENCH PCB:
TP1 MPREA
TP2 AGND Analog ground reference point
TP3 AGND Analog ground reference point
TP4 SPRER
TP5 DGND Digital ground reference point
5.5.1 Controller PCB LEDs
LED# LED Board Name Color Description
LED1 LAMP1 GRN When system is driving lamp #1 fiber optic cable
to the HVPS. LED blinks on whenever the laser
fires and during power on self-test of the HVPS.
