5.6 REMOVE/REPLACE PROCEDURE
This section provide procedures in the removing and replacement of major components in the VersaPulse
PowerSuite laser. Prior to removing/replacing any components in the system, the covers must be opened or
removed (i.e., side covers). Refer to Section 5.2 for the removal of any of the covers. Be sure all ESD protocols are
observed when removing/replacing any electronic component. Also, when removing/replacing any optical components,
be sure it is free of any contaminants.
5.6.1 Flashlamp Replacement
1. Turn the system off and disconnect the AC power cord from the AC power source.
2. Open the front door, remove the top and optics bench cover from the laser.
3. Drain the coolant. (Refer to Subtopic 5.6.4).
4. Measure B+ capacitor charge.
CAUTION: Do not touch the flashlamp wires or laser pod terminals unless the B+ charge is at 0 VDC.
This typically takes 10 minutes after disconnecting the power cord from the AC power source.
5. Disconnect the flashlamp wires from the terminal block.
Support the wire at the flashlamp end and carefully straighten out the red wire at the opposite end. (If
the wire is not supported at the flashlamp, the flashlamp may break.
6. Remove the flashlamp(s).
a. Remove the cavity assembly, if not already removed.
Be careful to note the location of the two cavity assembly O-rings between the cavity and the
manifold.
b. Remove the insulated end blocks surrounding the flashlamp ends. This releases the pressure from
the O-rings.
c. Put on latex gloves and clean the red wire of the old flashlamp with methanol and lens tissue.
