8. Return the switches on the Controller PCB to their normal positions.
SW3 to the RIGHT (enable autocalibration)
SW4 to the RIGHT (Service Attenuator out of the beam path)
3.3.3 Speaker Volume Adjustment
The VersaPulse PowerSuite emits various tones by way of a speaker as the system receives inputs from the
user, fires the laser or detects a fault condition. The volume of the tone can be raised or lowered by adjusting a
potentiometer on the Controller PCB. Use the following procedure to raise or lower the speaker volume.
1. Locate R8 on the Controller PCB.
2. Alternating between the READY and STANDBY buttons on the touchscreen display,
3. Adjust R8 on the Controller PCB until the volume out of the speaker is about mid-range.
4. Close the front door and repeat step 2. Verify the speaker can be heard. If not, adjust R8 until the
speaker can be heard (with the front door closed).
3.4 MECHANICAL ADJUSTMENTS
These procedures set the External Fiber Sense switch and the Blastshield Sense switch.
3.4.1 External Fiber Sense Switch Adjustment
Refer to Fig. 3.10 when performing the External Fiber Sense switch adjustment procedure.
