LUMENIS VersaPulse PowerSuite - 5.5 Test Points & LED Arrangement

7528%/(6+227,1* 9HUVD3XOVHPowerSuite6HULHV6HUYLFH0DQXDO
 5(9%
601 Fault 601 R Y +5 VDC is out of specification.
602 Fault 602 R Y +15 VDC is out of specification
603 Fault 603 R Y -15 VDC is out of specification
701 Fault 701 R N Coolant temperature too high.
702 Fault 702 R N Coolant temperature too low.
703 Fault 703 R N Coolant conductivity too high.
801 Fault 801 P N Inadvertent exposure test failed.
802 Fault 802 R N Inadvertent exposure.
803 Fault 803 P N Safety system test failed.
901 Fault 901 R Y No good lasers left.
5.5 TEST POINTS & LED ARRANGEMENT
CONTROLLER PCB:
Test Points # Name on PCB Function
TP1 Lamp1 LO = Fire Lamp 1 (or use as HVPS Mux Address)
TP2 Lamp2 LO = Fire Lamp 2 (or use as HVPS Mux Address)
TP3 Lamp3 LO = Fire Lamp 3 (or use as HVPS Mux Address)
TP4 Lamp4 LO = Fire Lamp 4 (or use as HVPS Mux Address)
TP5 LampModulate Frequency to Command HVPS Lamp IGBT
