7528%/(6+227,1* 9HUVD3XOVHPowerSuite6HULHV6HUYLFH0DQXDO
 5(9%
FIG. 5.1: FRONT VIEWS
Low Voltage
Power Supply
Insert a special tool (hex
wrench) through the hole on
bottom left of front door panel.
Push up on the tab inside the
hole to release the door. the
door will swing open towards
the right.
